PTFE UNIVERSAL PACKING (STYLE 11 & 12)
Kohinoor Non-Asbestos Packing
- PTFE UNIVERSAL PACKING (STYLE 11 & 12)
- PTFE GRAPHITE SOFT PACKING (STYLE 13)
- VALVE SEAL (STYLE 14)
- EXPANDED PTFE TAPE (STYLE 21)
- EXPANDED GRAPHITE PACKING (STYLE 41)
- EXPANDED GRAPHITE PACKING (STYLE 41SS)
- PURE CARBON PACKING (STYLE 42)
- PURE PTFE PACKING (STYLE 51)
- PURE PTFE PACKING DRY (STYLE 52)
- PTFE GRAPHITE PACKING (STYLE 61)
- PTFE GRAPHITE PACKING (STYLE 62)
- ARAMID PACKING (STYLE 71)
- PTFE PACKING GRAPHITE PACKING (STYLE 81)
- ARAMID & PTFE PACKING (STYLE 82)
- ARAMID & PTFE GRAPHITE PACKING (STYLE 83)
- PTFE & BLUE ASBESOTOS PACKING (STYLE 91)
- PTFE IMPREGNATED PACKING (STYLE 94)
- SYNTHETIC FIBRE PACKING ( STYLE 95)
- PTFE 100% PACKING
- HOLLOW AND SOLID CORE PACKING
- PTFE AND PTFE GRAPHITE PUTTY
- FDA VALVE SEAL (STYLE 14)
- FDA EXPANDED TAP (STYLE 21)
- FDA PTFE PACKING (STYLE 52)
Construction :
Extruded soft packing made from PTFE and high temperature lubricant. Available in square and round sections.Application :
Suitable for pumps, valves and many other static applications. Due to the chemical inertness of PTFE, it can be used with all substances. Offers excellent sealing when used in place of gasket or jointing in flanges in almost all type of industries.Standard Packing :
- 3 mm - 30 mts.
- 4 mm - 20 mtrs.
- 5 mm to 8 mm - 10 mtrs.
- 10 mm to 19 mm - 5 mtrs.
Service Parameters :
| Temp.(*C) | -100 to 260 °C |
| Pressure (kg/cm²) | 20 |
| pH Range | 0-14 |
| Velocity (mtrs/sec) | 4 |
* We can also supply custom size/length as per customer’s requirements
